Product CodeConfigurationCollection vol.CPD vol.Transfer Bag 1Transfer Bag 2Transfer Bag 3
4512240Single Blood Bag450 ml63 ml
4512265Double Blood Bag450 ml63 mlEmpty Transfer bag suitable for storage of plasma
4512230Triple Blood Bag450 ml63 mlEmpty Transfer bag suitable for storage of red cells, plasma or 5 days platelet storage
Product CodeConfigurationCollection vol.CPDA-1 vol.Transfer Bag 1Transfer Bag 2Transfer Bag 3
4512250Single Blood Bag450 ml63 ml
4512260Double Blood Bag450 ml63 mlEmpty Transfer bag suitable for storage of plasma
4512220Triple Blood Bag450 ml63 mlEmpty Transfer bag suitable for storage of red cells, plasma or 5 days platelet storage
4512280Quadruple Blood Bag450 ml63 mlEmpty Transfer bag suitable for storage of red cells, plasma and dry buffy-coat preparation, or 5 days platelet storage
Product CodeConfigurationCollection vol.CPD vol.SAGM vol.Transfer Bag 1Transfer Bag 2Transfer Bag 3
4512210Triple Blood Bag450 ml63 ml100 mlEmpty Transfer bag suitable for storage of red cells, plasma or 5 days platelet storageSAGM Transfer bag suitable for storage of red cells, plasma or 5 days platelet storage
4512290Quadruple Blood Bag450 ml63 ml100 mlEmpty Transfer bag suitable for storage of red cells, plasma and dry diluted buffy-coat preparation, or 5 days platelet storageEmpty Transfer bag suitable for storage of red cells, plasma dry or diluted buffy-coat preparation, or 5 days platelet storageSAGM Transfer bag suitable for storage of red cells, plasma or 5 days platelet storage

Description:

  1. Single Use
  2. Sterile Blood Bag system with CPDA-1 anticoagulant
  3. Sterile Blood Bag system with CPD anticoagulant and SAGM additive solution.

Classification:

  • Class IIb(According to MDD 93/42/EEC)

Method of sterilization:

  • Steam Sterilization

Shelf Life:

  • 36 months in the original unopened aluminium pouch
  • 15 days after opening the aluminium pouch

Conformities

  • ISO 3826

  • BP, Eur, USP



Anticoagulant

CPD and CPDA-1 anticoagulants make blood storage possible for up to 21 and 35 days respectively. SAGM provides RBC storage for up to 42 days.

Plastic Material:

Collection and Transfer bags made of Polyvinyl Chloride (PVC) with DEHP Platelet bags made of TOTM with adequate gas permeability which provides Platelet storage up to 5 days. Bags are embossed to avoid sticking to each other during autoclaving and to improve grip when handling, rounded edges reduce loss of blood components in the course of transfusion also these material made of transparent medical grade and particle free raw materials to facilitate monitoring in the course of transfusion.




Needle and Safety Guard:

  • Triple bevel cut needle with ultra-thin wall design, sand blasted and silicon lubricated surface of the cannula for painless venipuncture and reduced blood activation.
  • Ultra-thin walled silicon coated needle.
  • Minimal stress to the donor
  • Safety Guard improves safety of the operator and waste treatment staff by protection them from needle sticks.



Sampling Bag with accessories:

The sampling Bag is used to collect the first Blood Flow from the patient which prevents contamination from indigenous bacteria on the skin, diverts 10-30 ml of national blood.Blood collection tube enables multiple sampling using vacuum tubes.




Breakable Valve:

Enables ease of transferring blood components to transfer bags, it can be open by a double movement. The uniform break force of the click tip ensures easy breakability.




Labeling and Packaging:

Pharmed is registered by the international council for commonality in Blood Banking Automation (ICCBBA) to use international society of Blood Transfusion (ISBT 128) Bar code for systematic identification.




Specification of Labels are following:



  • Easy to write on
  • Tamper evident
  • Double color graphics
  • Resistance to tear, water and centrifugation
  • Labels are clear and easy to understand
  • Are barcoded which complies with ISBT 128
